Description
UPS(Uninterruptible power supply)
APC Smart-UPS On-Line, 10kVA/10kW, Rackmount 6U, 230V/400V, 4x 32A IEC outlets, Network Card+SmartSlot, Extended runtime, W/ custom PDU, W/ rail kit
Proven Industrial UPS power protection for control applications and harsh environments.
Order now at Deus.com.gh and have it delivered right at your doorstep.
Output
Max Configurable Power (Watts) 10.0kWatts / 10.0kVA
Output Voltage Distortion Less than 2 %
Output Frequency (sync to mains) 50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages 220 V, 240 V
Load Crest Factor 3 : 1
Topology Double conversion online
Waveform type Sine wave
Bypass Internal bypass (automatic and manual)
Input
Input frequency 40 – 70 Hz Auto-sensing
Input voltage range for main operations 100 – 275 Adjustable (half load), 173 – 476 Adjustable (half load)V
Other Input Voltages 220 V, 240 V, 380 V, 415 V
Batteries & Runtime
Battery type Lead-acid battery
Typical recharge time 1.5hour(s)
Replacement Battery APCRBC140
Expected Battery Life (years) 3 – 5
RBC Quantity 2
Battery Charge Power (Watts) 1.195kWatts
Extendable Run Time 1
Runtime View Runtime Graph
Efficiency View Efficiency Graph
Communications & Management
Interface Port(s) RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB
Emergency Power Off (EPO) Yes
Available SmartSlot™ Interface Quantity 1
Surge Protection and Filtering
Surge energy rating 480Joules
Physical
Maximum Height 263MM, 26.3CM
Maximum Width 432MM, 43.2CM
Maximum Depth 715MM, 71.5CM
Net Weight 111.82KG
Shipping weight 130.0KG
Shipping Height 461MM, 46.1CM
Shipping Width 1000MM, 100.0CM
Shipping Depth 600MM, 60.0CM
Color Black
